Description
The mini centrifuge is novel in appearance and versatile. It is equipped with two centrifugal rotors and multiple test tube sleeves for 2.0mL/1.5mL/ 0.5mL/0.2mL centrifuge tubes and 8×2×0.2mL PCR tube strips. Fully transparent round top cover with multi rotor equipped, and an open cover pause function and electronic timing fully embodied the design concept of humanization.
Application
- Serum extracted from whole blood
- Supernatant extraction of various samples
- Separation of blood cells
- Microbial sample processing
- Rapid sedimentation of samples
- Partition centrifugation for PCR experiments
Features
- Large radius with 8-hole rotor design, 1.5-fold stronger centrifugal force.
- Top cover opens automatically for easy one-handed operation.
- Snap-on design for easy rotor replacement and removal.
- Noise reduction function, near silent operation.
- The maintenance-free motor is durable, safe and reliable.
- Exquisite appearance and compact size.
Specifications
| Model | CFG-Mini4Y | CFG-Mini6Y | CFG-Mini7Y | CFG-Mini10Y | CFG-Mini10YS |
| Speed | 4000rpm | 6000rpm | 7000rpm | 10000rpm | 3000-10000rpm |
| Max.RCF | 860xg | 2000xg | 2600xg | 5400xg | 500-5400xg |
| Capacity | Centrifuge Tube: 8×2.0mL/1.5mL/0.5mL/0.2mL
PCR tube strips:8×4×0.2mL | ||||
| Timer | 1~99min59s | ||||
| Sound Emission | ≤ 45dB | ≤ 55dB | |||
| Electricity | 220V/110V, 50-60Hz | ||||
| Dimension(W*D*H) | 160*176*135mm | ||||
| N.W./G.W. | 1.6kg/2.1kg | ||||
| Shipping Dimension(L*W*H) | 290*230*210mm | ||||
Equipped accessories
| Strip rotor |  | For 0.2mL×32 tubes |
| 8-position rotor |  | For 1.5/2.0ml×8 tubes |
| Tube adaptor |  | For 0.5ml tubes |
