Description
- Easy programmin gto achieve high accuracy of speed control.
- Easy operation with intuitive menu and easy-to-read display.
- Rotor speed can be set and displayed by RPM or G-force.
- Maintenance-free brush-less DC motor.
- Quick spin function with press and hold pulse key.
- Lid with electric lock and automatic release function saves processing time.
- Automatic self-diagnosis on startup, showing accumulative running time and last running parameters.
- Braking time 2 steps adjustable.
Specifications
| Specification | CFG-4.5D |
| Speed Range | 300-4500rpm, increment: 100rpm |
| Max RCF | 2490×g |
| Speed Accuracy | ±20rpm |
| Rotor Type | A12-10P, A6-50P |
| Run Time | 30sec-99min HOLD (Continuous operation) |
| Motor | Brush-less DC motor |
| Display | LCD |
| Safety Devices | Door interlock; Over-speed detector; Automatic internal diagnosis |
| Acceleration/Braking time | A12-10P: 20s↑13s↓ A6-50P: 20s↑20 s /90 s↓ |
| Power | Single-phase, 100V-240V,50Hz/60Hz, 3A 70W |
| Dimension(W×D×H) | 354mm×304mm×215mm |
| Weight | 6 kg |
| Advanced Features | Speed/RCF switch; Short-time run function; Sound-alert function |
| Package | Carton |
| Package Size | 470mm*420mm*320mm |
| Gross Weight | 9kg |
Available rotors
 | Cat. No.19200921
for CFG-4.5D &CFG-4D&CFG-4D-E Max. speed: 4500rpm Max. RCF: 2490×g Rotor capacity: 8x15mL,12x10mL Rotor material: High strength plastic |
 | Cat. No.19100197
For CFG-4D(A6-50P) Max. speed: 4000rpm Max. RCF: 1800×g Rotor capacity: 50ml×6 or 15ml×6 Rotor material: High strength plastic |
Cat. No.19200921 and Cat. No.19100197 are not interchangeable.
| Available tubes | Tube quantity | Dimension (Ф×L, mm) | Maximum speed(rpm) | Radius (cm) | Maximum RCF (×g) |
| 15mL con | 8 | 17×120 | 4500 | 11 | 2490 |
| 1.5-5mL vacu | 12 | 13×75 | 4500 | 9.8 | 2218 |
| 4-7 mL vacu | 12 | 13×100 | 4500 | 11 | 2490 |
| 16×75 | 4500 | 2218 | |||
| 8.5-10 mL vacu | 12 | 16×107 | 4500 | 11 | 2490 |
| 2.7-3 mL (EU) collection tube | 12 | 11×66 | 4500 | 9.8 | 2218 |
| 7.5-8.2 mL (EU) collection tube | 12 | 15×92 | 4500 | 11 | 2490 |
Note: Made of plastic, Cat. No.19200921 rotor cannot be autoclaved or applied with UV irradiation. Regular sterilization is recommended.
