Description
This instrument complies with the ergonomic principle, with superior optical performance, long operation time and low observation fatigue. It is suitable for medical institutions at all levels to do research demonstration, routine laboratory examinations, biology, bacteriology, clinical trials and teaching.
Specifications
| Model | MSC-B103(Sliding) |
| Optics | Finite Distance Optical System |
| Observation Tube | Tilting binocular,interpupillary 55-75mm |
| Viewing Head | Sliding head,inclined at 45° |
| Optical Coating | Transmittance ≥ 95% |
| Eyepieces | Wide field eyepiece WF10×18mm |
| Objective | Achromatic objective 4X, 10X, *20X,40X, 100X |
| *Plan achromatic objective: 4X, 10X, 20X, 40X, 100X | |
| Nosepiece | Quadruple nosepiece / *Quintuple nosepiece |
| Stage | Double layers mechanical stage 120×115mm / 70×30mm |
| Condenser | Abbe NA1.25 with iris diaphragm & filter |
| Focusing | Coaxial coarse and fine adjustment, fine division 0.002mm, coarse stroke 37.7mm per rotation, fine stroke 0.2mm per rotation, moving range 22mm |
| Illumination | 3W LED illumination, brightness adjustable |
| *6V 20W Halogen lamp, brightness adjustable | |
| Electricity | 100-240V AC,50/60Hz |
| Package Dimension (W*D*H) (mm) | 370*260*470 |
| Gross Weight (Kg) | 6 |
| *Optional | MSC-B103T: Microscope camera (standard imaging software) / Win 10 Pad / Digital display |
