Description
Water Bath is a multi-function thermostat water tank controlled by PID. It’s an indispensable tool in the fields of pharmaceutical, biochemistry, scientific research, environmental protection and etc.
- High quality water tank: Wear-proof and corrosion-resistant stainless steel coated by Teflon.
- With large-diameter drain valve for quickly discharge.
- 10 programs stored for fast operation.
- Controlled by PID, high precision and tiny fluctuation.
- Big size TFT display.
- Built-in liquid level sensor with buzzer alarm.
- Good uniformity due to a big heating plate fixed under the tank bottom.
Specifications
| Model | WB2 | WB2-3 | WB5 | WB10-C |
| Capacity | 2L | 2L×3 | 5L | 10L |
| Temp.Control Range | RT. +5~100℃ | |||
| Timer | 1min~99h59min | |||
| Temp.Accuracy | ±0.3℃ | |||
| Temp.Uniformity | ±0.3℃（37℃） | |||
| Liquid Level Alarm | Yes | |||
| Voltage | AC100~120V/AC200~240V 50~60Hz | |||
| Power | 250W | 750W | 550W | 1000W |
| Drain Method | Manual | Drain pump | Manual | Drain outlet |
| Tank Dimension
(W*D*H) | 135*150*150
mm | 3*135*150*150
mm | 155*300*150
mm | 240*300*150
mm |
| Dimension
(W*D*H) | 205*253*204
mm | 625*253*204
mm | 205*395*210
mm | 290*395*210
mm |
| N.W./G.W. | 3kg/6kg | 5.5kg/12.6kg | 6kg/8kg | 9kg/11.7kg |
| Shipping Dimension
(L*W*H) | 400*380*290
mm
| 880*360*310 | 550*290*310
mm | 570*410*300
mm |
