High Speed Centrifuge, CFG-18.5JP

  • High Speed Centrifuge, CFG-18.5JP

Description

Description

The centrifuge adopts microcomputer control, large-screen color LCD display, and full touch-screen operation interface to directly set the working program, RCF, speed, time, acceleration and deceleration, and rotor model.

Features

  1. Brushless AC variable frequency motor drive and special drive module ensure the reliability of the circuit.
  2. Double door cover lock system, starting means locking, ensuring safe operation.
  3. Provides 20 kinds of working program storage, users can freely program and call theirworking parameters, which is easy to use and improves work efficiency.
  4. Two timing functions: at set rpm and start timing, and the jog is short spin function.
  5. Differential centrifugation: Five differential centrifugation programs are reserved, and users can set them according to their needs.
  6. Double-layer steel structure and stainless steel centrifugal chamber to avoid corrosion.
  7. Automatic balance and imbalance protection. When an error or imbalance occurs, an audible alarm signal will be issued and the centrifuge will automatically stop running.
  8. Easily adjust speed, RCF, time and temperature during operation without
  9. Braking function that can effectively prevent samples from being resuspended and protect sensitive samples.
  10. Multi-stagedamping design ensures the best sample centrifugation effect.
  11. Countdown function: Countdown in seconds and display remaining working time in real time.
  12. Automatically recognizes the magnetic rotor, no need to manually set the rotor model, and has overspeed protection.
  13. The rotor can be autoclaved at 121°C for more than 2 hours. Airtight angle rotor with high biological safety.

Specifications

ModelCFG-18.5JP
Max.Speed18800rpm
Max.RCF26870xg
Max.Capacity10mlx12
Speed Accuracy±10rpm
Timing Range1s~99h59min59s/Jog (short spin)
Sound Emission≤58dB
ElectricityAC 220V, 50Hz, 10A
Power400W
Dimension(W*D*H)426*322*340mm
N.W./G.W.28kg/31kg
Package Dimension(W*D*H)490*430*480mm

Rotor Configuration

RotorCapacityMax. SpeedMax.RCF
H0.136Blood Capillary



L75mmx36 tube

12000rpm16904xg
H0.2320.2mlx4x8tube13500rpm14059xg
H0.2640.2mlx8x8tube13000rpm14926xg
H0.5120.5mlx1218800rpm18967xg
H0.5240.5mlx2418800rpm26870xg
H0.5480.5mlx4813000rpm14737xg
H02121.5/2.2mlx1218800rpm26870xg
H02241.5/2.2mlx2415800rpm24365xg
H03123mlx12



Vacuum test tube

8000rpm4866xg
H05125mlx1216000rpm19462xg
H07125mlx12



Vacuum test tube

8000rpm7119xg
H101210mlx1213500rpm17645xg
H06125mlx12



Cryogenic vials

13000rpm16155xg
