Description
Specifications
| Model | MSC-V201 |
| Optical System | Infinite Optical System |
| Viewing Head | 10-inch display screen |
| Video Adapter | C Mount 0.5×/1× |
| Objective | Infinite Plan Achromatic Objective：4×，10×，*20×，40×，100× |
| Nosepiece | Quadruple Nosepiece/*Quintuple Nosepiece |
| Stage | Double Layers Mechanical Stage 140X135mm, range of movement: 75X50mm |
| Condense | Abbe Condenser N.A. 1.25 with Iris Diaphragm & Filter |
| Focusing System | Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation,
Fine Stroke 0.2mm per Rotation, Moving Range 20mm |
| Illumination | 3W LED light, brightness continuously adjustable |
| *Optional | Turret Phase Contrast Kit；Dark Field Attachment；Fluorescent Attachment
Microscope Camera/win10 Pad/Digital display |
| *Optional configuration | |
